GENERAL SPECIFICATIONS

HULL LENGTH: 120'-0"

HULL WIDTH: 68'-0"

HULL DEPTH: 10'-0"

LENGTH OVERALL: 137'-0"

WIDTH OVERALL: 74'-0"

FOOTING LENGTH: 32'-0"

FOOTING WIDTH: 16'-0"

FOOTING DEPTH: 2'-6"

LEG LENGTH OVERALL: 215-0"

LEG DIAMETER: 72"

LEG THICKNESS: 1"

LEG MATERIAL: API 5L-X65

JACKING SPECIFICATIONS

JACKS PER LEG QTY: TEN

JACKING RATING / JACK: 65.75 S-TONS

HOLDING RATING / JACK: 87.67 S-TONS

JACKING RATING / LEG: 657.50 S-TONS

HOLDING RATING / LEG: 876.7 S-TONS

TOTAL JACKS QTY: 30 TOTAL

JACKING RATING: 1972.5 S-TONS

TOTAL HOLDING RATING: 2630.0 S-TONS

CAPACITIES

FUEL OIL CAPACITY: 14,753 GAL

POTABLE WATER CAPACITY: 18,992 GAL

JACKING HYDRAULIC OIL: 3688 GAL

CRANE HYDRAULIC OIL: 3714 GAL

ACCOMMODATIONS

ACCOMMODATION CREW: 8 MEN

ACCOMMODATION VIP: 2 MAN

ACCOMMODATION PACS: 34 MEN

ACCOMMODATION TOTAL: 44 MEN

MIF Class 215 Liftboat

Main Deck

Outboard Profile

Levels 1 & 2

Levels 3 & 4
